Locate both interior and engine compartment power distribution panels before troubleshooting any electrical fault, then compare each slot number with the printed legend on the cover. This step prevents removing the wrong insert and avoids unnecessary system disruptions.

The cabin-mounted unit is typically positioned under the dashboard near the driver side and contains lower-rated inserts such as 7.5A, 10A, and 15A, responsible for lighting, audio, and control switches. The engine compartment unit handles higher current loads, often ranging from 20A to 60A, supporting cooling fans, ABS, and ignition circuits.

Check amperage values before replacement; installing a higher-rated insert can lead to overheating or wiring damage. Each circuit is designed for a specific current limit, and deviation increases the risk of component failure.

Use a multimeter or test light to confirm a failed insert rather than relying only on visual inspection. A broken internal strip is a clear sign, but voltage testing across both terminals provides accurate confirmation.

Keep spare inserts and a puller tool inside the vehicle to handle minor electrical issues on the road. Having common ratings available allows quick restoration of systems like wipers, interior lights, or power outlets.

Scion tC fuse box diagram and circuit identification guide

scion tc fuse box diagram

Use the panel cover legend to match each numbered slot with its assigned circuit before removal, since identical amperage values may control different systems such as lighting, audio, or control modules.

The interior distribution unit contains lower current ratings from 7.5A to 20A, handling dashboard electronics, interior lights, and accessory sockets. The engine compartment unit includes higher ratings from 20A up to 60A, supporting cooling fans, ABS, and ignition-related systems.

Typical circuit roles

  • 7.5A – instrument cluster and warning indicators
  • 10A – interior lighting and audio system
  • 15A – power outlets and accessory sockets
  • 20A – wiper motor and washer system
  • 40A+ – radiator fan and main power circuits

Identify each circuit by both slot number and label, not just amperage, to avoid disconnecting the wrong component during troubleshooting or replacement.

Relays located рядом the panel manage high-load operations such as starter activation and fuel pump control. Swapping identical relay units can help verify faults without additional diagnostic tools.

Fuse box locations in cabin and engine bay with access steps

Remove the lower dashboard cover on the driver side to access the interior power distribution panel, usually positioned near the left knee area. Pull the plastic trim outward to release retaining clips without using excessive force.

Some configurations place this panel behind a side dashboard cap visible only when the door is open. Carefully pry the cap off using fingers or a trim tool to avoid damaging the surface.

Engine compartment access

Locate the main electrical distribution unit near the battery under the hood, enclosed by a protective plastic cover with locking tabs. Press the tabs and lift the lid to expose high-current inserts and relay components.

Ensure ignition is switched off before handling any electrical parts. After inspection or replacement, press the cover firmly until all clips lock to prevent moisture and dirt from entering the panel.
