Locate the interior power distribution panel near the driver side dashboard and verify each slot using printed amperage values before removing any insert. This prevents installing an incorrect rating that may damage wiring or connected systems.
The cabin-mounted unit controls circuits such as interior lighting, dashboard electronics, power outlets, and climate system components. Ratings typically range from 5A to 30A, with each position labeled for identification. A second distribution center under the hood manages higher current paths including cooling fan, ignition supply, and charging connections.
Use a multimeter or test light to check voltage on both contact points of each insert. If power appears only on one side, the internal strip is broken. Repeated failure indicates wiring damage, poor grounding, or a component drawing excessive current.
Keep spare inserts in common ratings such as 10A, 15A, and 20A inside the vehicle. Store a printed circuit reference nearby to quickly identify problem areas during faults like non working accessories or lighting issues.
Peugeot Expert Van Fuse Box Diagram Guide
Check the panel cover legend before removing any insert to match each slot with its assigned circuit such as headlights, wipers, or dashboard systems.
The interior distribution unit handles low and medium load circuits, typically rated between 5A and 30A. Each position corresponds to a specific function, allowing quick identification during electrical faults.
- 5A–10A for control modules and lighting
- 15A for wipers and signal systems
- 20A–30A for power outlets and blower motor
Under the hood, the main power center supports higher current paths and includes larger rated inserts and relays for components that draw significant power.
- Cooling fan circuit
- Ignition supply lines
- Charging system connections
Replace damaged inserts only with identical amperage ratings to prevent wiring overheating or repeated failure under normal load conditions.
Use a multimeter to verify continuity across both terminals, confirming proper current flow and helping detect faults in connected wiring or components.
Fuse Box Location in Peugeot Expert Van Cabin and Engine Compartment
Open the driver side lower dash panel to access the interior power distribution unit, usually positioned behind a plastic cover near the steering column or glove compartment area.
This cabin-mounted unit is designed for quick access and contains circuits for lighting, dashboard controls, audio system, and auxiliary power outlets. Use a flashlight to clearly read slot markings and amperage labels.
Remove the cover by releasing its clips, taking care not to damage the plastic tabs. The inner side often includes a printed layout that helps identify each circuit.
In some configurations, an additional panel may be located on the side of the dashboard, accessible when the driver door is open. This secondary unit supports extra control modules and accessories.
Locate the engine compartment power center near the battery, enclosed in a sealed housing that protects high current connections from heat and moisture exposure.
Release the locking tabs and lift the cover straight up to access larger inserts and relays linked to systems with higher electrical demand.
These circuits typically include cooling fan operation, ignition supply, and charging connections, all requiring stable power delivery.
Ensure all covers are securely reinstalled after inspection to prevent dirt, moisture, or accidental contact with live terminals.
