Check the power distribution unit under the dashboard first: the interior panel typically sits to the left of the steering column, hidden behind a removable cover. Inside, each circuit is marked with abbreviations like ACC, IGN, TAIL, which correspond to accessory systems, ignition chain, and rear lighting. Use the cover’s reverse side for quick reference–manufacturers often print the circuit map directly there.
Under the hood, a second module handles higher-load components such as cooling fans and headlamps. This compartment is near the battery and contains square relays alongside blade-type safety elements. Look for amperage values stamped on top–common ratings include 10A, 15A, and 30A. Replacing with a mismatched value risks wiring damage or repeated shutdown of the same circuit.
If a specific function fails–like the radio or power windows–match the label from the interior panel to its slot number. Pull the element using plastic tweezers (often included in the panel) and inspect the metal strip inside. A broken strip signals a blown component. For intermittent faults, check relay seating; a loose relay can interrupt current without visible damage.
Color coding also helps: blue usually indicates 15A, red marks 10A, and green stands for 30A. Keep a small set of replacements in the glove compartment to avoid roadside delays. For deeper diagnostics, trace the circuit path using a multimeter–probe both sides of the slot to confirm voltage flow and isolate failures beyond the distribution unit.
2014 Scion xB Fuse Box Diagram: Practical Guide for Location, Identification, and Troubleshooting
Locate the primary electrical panel under the dashboard on the driver’s side and the secondary unit in the engine compartment near the battery; remove the plastic cover to access the circuit layout map printed on its underside, which matches each slot with amperage ratings such as 10A, 15A, or 30A for systems like headlights, audio, and HVAC. Use a puller tool to extract a suspect element and inspect the metal strip inside–if it is broken or darkened, replace it with the same rating to avoid wiring damage or malfunction of connected components.
Identify circuits by cross-referencing the labeled grid on the cover with the vehicle manual: for example, “ACC” typically handles accessory power, “EFI” relates to fuel injection, and “DOME” controls interior lighting; mismatched replacements often lead to repeated failure or intermittent issues such as flickering lights or non-responsive infotainment.
Troubleshooting electrical faults requires checking not only the protective inserts but also surrounding relays and connectors; if a newly installed element fails instantly, inspect for short circuits along the wiring harness, especially near high-vibration zones and heat sources like the engine block, and verify ground points are clean and tightly secured to prevent voltage drops.
Exact Location of Interior and Engine Bay Fuse Boxes in 2014 Scion xB with Access Instructions
Open the driver-side door and look beneath the dashboard, slightly left of the steering column: the interior electrical panel is mounted behind a small rectangular cover. Pull the lower edge of this cover outward using your fingers; no tools are required. The panel sits above the footwell trim, aligned with the brake pedal area, making it accessible while seated or crouched beside the door.
To remove the cover cleanly, follow these steps:
- Grip the bottom notch of the plastic lid
- Pull straight toward you without twisting
- Release the upper clips by easing pressure upward
- Set the cover aside to avoid breaking the tabs
The engine compartment power distribution unit is positioned near the battery on the left side of the engine bay (when facing the vehicle from the front). It is a black rectangular housing with a snap-on lid. You will find it directly adjacent to the air intake assembly and close to the fender edge.
Engine Bay Access Instructions
Lift the hood using the interior release lever and secure it with the prop rod. Locate the rectangular housing beside the battery. Press the locking tabs on both sides of the lid simultaneously, then lift upward. If resistance is present, apply even pressure on both clips rather than forcing one side.
Key access details:
- No screwdriver is needed; the lid is clip-secured
- Open only when the engine is off
- Keep moisture and debris away from the open compartment
- Ensure the lid clicks firmly back into place after inspection
Interior Panel Access Notes
Inside the cabin, clearance is tighter. Slide the seat backward fully to create working space. A flashlight helps identify labels molded into the plastic backing. The panel is mounted vertically, so components are visible immediately after removing the cover. Reattach the cover by aligning the top tabs first, then pressing the bottom until it snaps flush.
