Locate the interior and engine bay power distribution panels before checking any electrical fault. One panel is installed under the dashboard on the driver side, while another sits in the engine compartment near the battery. Each section protects separate systems such as ignition, lighting, cooling fan, and audio unit.
Match each protective insert by amperage and position using the printed chart on the cover. Common ratings include 7.5A for control circuits, 10A for lighting, 15A for accessories, and 30A for high-load components like blower motor. Color coding allows quick identification during inspection.
Inspect the metal strip inside each element before replacement to confirm failure. A broken or darkened strip indicates overload or short circuit. Always switch off ignition and remove the key before accessing panels to avoid electrical damage or accidental shorting.
1995 Honda Civic EX Fuse Diagram with Locations and Circuit Assignments
Use the panel cover chart to match each slot number with its assigned circuit before replacing any protective insert. The layout is divided between the cabin panel under the dashboard and the engine compartment unit near the battery.
Interior positions typically control lighting, radio, instrument cluster, and power accessories. Each slot is numbered, and the corresponding list shows function and current rating, allowing quick identification of the affected system.
Engine compartment slots handle higher load components such as cooling fan, ignition system, and charging circuit. These positions usually have higher amperage values, often ranging from 20A to 40A, and are grouped separately from low-current circuits.
Follow the printed assignment list carefully to avoid incorrect placement. One slot may support multiple related systems, such as dashboard illumination and tail lights, so incorrect installation can disable several functions at once.
Typical ratings include 7.5A for control modules, 10A for lighting circuits, 15A for accessory outlets, and 30A for motors. Each insert uses a color code that matches its rating, making visual identification faster during inspection.
Check each element by inspecting the internal metal strip for breaks or burn marks. A damaged strip indicates overload or short circuit within that specific circuit path.
Replace only with identical amperage and confirm the slot number before installation. Using a higher rating increases risk of wiring damage, while a lower value may cause repeated failures under normal load.
Where to find interior and under hood fuse panels in 1995 Civic EX
Open the driver door and look beneath the dashboard on the left side to access the interior panel. It is mounted low near the kick panel and protected by a small plastic cover that can be removed without tools.
Interior panel position details
This section controls cabin-related circuits such as radio, dashboard lighting, turn signals, and power accessories. The layout is arranged in rows with clearly marked slots and amperage values printed on the cover.
- Driver-side lower dashboard area
- Behind removable plastic cover
- Close to steering column and kick panel
Ensure ignition is off before removing the cover to avoid accidental short circuits.
Engine compartment panel location
Lift the hood and locate the main power distribution unit near the battery. It is enclosed in a rectangular plastic housing with clips securing the lid.
- Positioned next to battery
- Near inner fender or firewall area
- Covered by sealed protective lid
This section handles higher current systems such as cooling fan, ignition, and charging circuit, making it the first place to check when major components stop working.
