Locate the main access point under the dashboard on the driver’s side to identify each current protector. Use the numbering on the cover to cross-reference circuits such as headlights, ignition, and climate control. Label each connector to prevent misplacement during inspections or replacements.
For models produced between 2012 and 2018, the auxiliary relay section is situated near the steering column, containing compact fuses for the audio system, power windows, and central locking mechanisms. Consult the stamped legend on the panel lid to distinguish amperage values and avoid accidental overloads.
Exterior lighting circuits are protected by high-capacity holders mounted on the engine compartment firewall. Check the orientation of each holder before inserting replacement elements, ensuring proper seating to maintain uninterrupted power flow. Regular verification of contacts reduces the risk of short circuits and intermittent failures.
For troubleshooting cabin electronics, detach the lower trim carefully to expose secondary protective elements for infotainment modules, seat heaters, and accessory sockets. Always use the recommended rating for replacements and maintain a consistent sequence when reinstalling panels to preserve the original configuration.
When addressing issues with engine control or fuel injection units, refer to the under-hood panel located near the battery. Each circuit slot is numbered and color-coded, which allows precise identification of sensor feeds, ignition coils, and auxiliary pumps. Avoid forcing connectors to prevent terminal damage.
Ford Falcon Electrical Panel Layout
Locate the main control panel beneath the driver’s side dashboard; it contains all primary protective devices for the vehicle’s circuits. Remove the cover carefully to access numbered slots corresponding to each system.
Slots 1 through 5 are dedicated to ignition, headlights, and fuel pump. Each connector is color-coded and rated between 10A and 20A. Check the marking on each clip before replacement to avoid overloading.
Secondary access points on the passenger side console manage the climate control, infotainment, and auxiliary sockets. These connectors are smaller and typically use 5A to 15A ratings.
Relay Positions and Identification
Relays controlling the starter motor, horn, and wipers are positioned in the upper section of the panel. They are black or gray, rectangular, and snap in with a firm click. Test each with a multimeter to confirm continuity before switching.
Integrated modules for safety features like airbags and ABS are located near the center of the enclosure. Avoid touching connectors while the battery is live; disconnecting the negative terminal first prevents short circuits.
Label each replacement clip with its amperage and original location. Using the wrong rating can blow circuits, causing expensive repairs. Keep a small diagram or printed chart in the glove compartment for reference.
Maintenance Tips
Check terminals for corrosion or discoloration every 6 months. Light green or white residue indicates oxidation; clean gently with a non-conductive brush. Moisture trapped in connectors can trigger intermittent failures.
For upgrades such as LED lighting or aftermarket audio, ensure new protective devices match the original amperage. Insert carefully; forcing a slot may damage the panel, making future replacements difficult.
Locating the Fuse Panel in Different Falcon Variants
For 1960s models, the power distribution panel resides under the dashboard, slightly left of the steering column. Remove the lower trim to access the cluster of relays and protective links, which are mounted on a metal bracket. Labels are embossed on the panel itself, eliminating the need for extra guides.
In early 1970s variants, the service unit shifted to the engine compartment. Look near the battery on the driver’s side; a rectangular cover conceals multiple circuits. Check the orientation carefully: some terminals face forward while others point toward the firewall, which affects ease of replacement.
Mid-1970s sedans often feature dual compartments. One small module remains inside the cabin, next to the glove compartment, while a larger cluster is under the hood. The interior module handles lighting and accessory circuits, whereas the under-hood cluster protects ignition, fuel pump, and cooling fan circuits.
For late 1970s to early 1980s coupes, the central distribution unit moved to the passenger side footwell. Access requires detaching a plastic panel with simple clips. Once open, the internal layout shows mini-relays and micro-links arranged in rows, each stamped with a numeric code for identification.
Sport trims from the same era sometimes include a secondary protective assembly in the rear trunk area. Typically mounted behind the spare tire, this module governs rear lights, auxiliary power outlets, and heated rear window circuits. Labels are printed on the inside of the cover for quick reference.
Station wagons and utility versions often combine multiple control clusters. A primary module remains under the hood, while secondary panels are inside near the driver’s knee area. Always ensure the ignition is off before opening any compartment, as some terminals remain live even with the engine stopped.
